Leveller Series Model：         BSL     Precision Roll Leveller  Model BSL-100 BSL-150 BSL-200 BSL-300 BSL-500  Max materialwidth(mm) 100 150 200 300 500  Material thickness(mm) 0.1～0.8 0.1～0.8 0.1～0.8 0.1～0.8 0.1～0.8  Feeding Speed(m/min) 0～20 0～20 0～20 0～20 0～20  Straightening roller ф16 ф16 ф16 ф22 ф22  Auxiliary straightening roller ф16 ф16 ф16 ф22 ф22 1.This manchine is suitable for the precise eletronic products of computer connector, electronic component and conducting wire shelf etc. 2.The straighten roller with hard chrome finishing,the eletricity part specially equips with the feeding shelf and press of wiring of emergancy stop equipment.Multiple prtection,safe and reliable. 3.Additionally set up the upper and lower straightening rollers,it will be flexibly and conveniently adjust to straighten the material. 4.The material width is 400-600 and thickness is 0.1-0.6t,welcome to call us for reference.
