Model：

High speed NC servo roll feeder

FEATURES:
1.Employing the vibration-resistan motor.
2.Pilot releasing by air cylinder is standard.
3.Control panel built to with stand the strong vibration of the press.
4.Convenient one-feed mode makes trying easy.

Model	LC-150II	LC-250II	LC-350II
Material width(mm)	Max150mm	Max250mm	Max350mm
Material thickness(mm)	Max2.33mm	Max2.0mm	Max1.2mm
Motor	0.4KW	0.4KW	0.4KW
Roll release	Air cylinder	Air cylinder	Air cylinder
Max feed length	9999.9mm	9999.9mm	9999.9mm
Top speed	80m/min	80m/min	80m/min
